The PVmet product line is a robust and cost-effective weather station solution. Sensors include:
PVmet supports many popular data loggers including the Acquisuite A8810 & A8820, FlexOM Gateway, VSN700, Data Manager M, as well as Smartloggers 1000A, 2000, 3000, and 3000A. Connectivity options include Modbus RTU/RS485 and Modbus TCP/Ethernet.
Model | Irradiance - Global or Plane of Array | Ambient Air Temp | Back of Panel Temp (BOM) | Wind | Other Sensors Included | Optional Sensors |
---|---|---|---|---|---|---|
PVmet 75 | 1 RainWise sensor for either | Included | Includes 1 | BOM temp | ||
PVmet 100 | 1 silicon diode sensor for either, sensor can be adjusted to match PV array angle | Included | Includes 1 | Speed and direction | Second BOM temp sensor | BOM temp |
PVmet 150 | Includes a precise second-class thermopile pyranometer sensor. Supports 1 additional pyranometer. | Included | Includes 1 | EKO thermopile pyranometer, BOM temp | ||
PVmet 200 | Includes 2 EKO sensors | Included | Includes 1 | Speed and direction (aervane) | BOM temp | |
PVmet 330 | Includes global irradiance sensor. Supports 1 additional pyranometer for plane of array. | Included | Includes 1 | Speed and direction | Barometric pressure, rain gauge | EKO thermopile pyranometer, BOM temp |
PVmet 500 | Supports 3 irradiance sensors (all classes and standards of Thermopile & Silicon Diode technologies). Can monitor irradiance for albedo (bifacial PV) & diffused. | Included | Supports 3 | Supports ultrasonic or mini aervane | Relative humidity, barometric pressure | Rain gauge |
PVMet weather stations are arrive fully configured, assembled, and ready to be installed. The world's leading inverter companies trust PVmet. Contact PowerWise by calling 1-207-370-6517, email sales@powerwisesystems.com, or use our web form.
